$1.00
Long Haul Trucker—
$1.00
The Story
26"
| SIZE | 42cm | 46cm | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm | 62cm |
|---|---|---|---|---|---|---|---|---|---|
| Reach | 367.2 | 371.3 | 374.5 | 374.6 | 379.4 | 388.3 | 393.5 | 402.5 | 400.5 |
| Stack | 497.2 | 502.9 | 532.3 | 550.3 | 568.3 | 588.1 | 606.1 | 623.3 | 643.2 |
| Head Tube Angle | 70.0° | 70.0° | 71.0° | 71.0° | 71.0° | 71.0° | 71.0° | 71.5° | 71.5° |
| Head Tube Length | 110.7 | 116.7 | 144.0 | 163.0 | 182.0 | 203.0 | 222.0 | 238.0 | 259.0 |
| Seat Tube Length | 420 | 460 | 500 | 520 | 540 | 560 | 580 | 600 | 620 |
| BB Drop | 47.0 | 47.0 | 47.0 | 47.0 | 47.0 | 47.0 | 47.0 | 47.0 | 47.0 |
| Wheelbase | 1036.6 | 1042.7 | 1046.8 | 1053.1 | 1064.0 | 1079.8 | 1091.2 | 1100.4 | 1105.1 |
| Chainstay Length | 460.0 | 460.0 | 460.0 | 460.0 | 460.0 | 460.0 | 460.0 | 460.0 | 460.0 |
| Top Tube Length, Actual | 492.7 | 508.4 | 525.4 | 535.0 | 549.7 | 564.5 | 580.3 | 594.8 | 603.8 |
| Top Tube Length, Effective | 505.0 | 515.0 | 530.0 | 540.0 | 555.0 | 570.0 | 586.0 | 600.0 | 610.0 |
| Seat Tube Angle | 75.0° | 74.5° | 74.0° | 73.5° | 73.0° | 73.0° | 72.5° | 72.5° | 72.0° |
| Standover Height | 702.1 | 723.2 | 756.1 | 774.5 | 792.4 | 811.9 | 829.7 | 847.9 | 866.6 |
| Fork Length | 376.0 | 376.0 | 376.0 | 376.0 | 376.0 | 376.0 | 376.0 | 376.0 | 376.0 |
| Fork Rake | 45.0 | 45.0 | 45.0 | 45.0 | 45.0 | 45.0 | 45.0 | 45.0 | 45.0 |
700c
| SIZE | 56cm(700c) | 58cm(700c) | 60cm(700c) | 62cm(700c) | 64cm(700c) |
|---|---|---|---|---|---|
| Reach | 389.3 | 394.4 | 403.0 | 401.0 | 406.1 |
| Stack | 588.0 | 606.1 | 623.2 | 643.2 | 658.4 |
| Head Tube Angle | 72.0° | 72.0° | 72.0° | 72.0° | 72.0° |
| Head Tube Length | 152.0 | 171.0 | 189.0 | 210.0 | 226.0 |
| Seat Tube Length | 560.0 | 580.0 | 600.0 | 620.0 | 640.0 |
| BB Drop | 78.0 | 78.0 | 78.0 | 78.0 | 78.0 |
| Wheelbase | 1055.6 | 1066.7 | 1080.8 | 1085.3 | 1095.3 |
| Chainstay Length | 460.0 | 460.0 | 460.0 | 460.0 | 460.0 |
| Top Tube Length, Actual | 564.5 | 580.2 | 594.8 | 603.9 | 615.0 |
| Top Tube Length, Effective | 570.0 | 586.0 | 600.0 | 610.0 | 620.0 |
| Seat Tube Angle | 73.0° | 72.5° | 72.5° | 72.0° | 72.0° |
| Standover Height | 811.9 | 829.8 | 847.8 | 866.5 | 883.6 |
| Fork Length | 390.0 | 390.0 | 390.0 | 390.0 | 390.0 |
| Fork Rake | 45.0 | 45.0 | 45.0 | 45.0 | 45.0 |
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Description
26"
| SIZE | 42cm | 46cm | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm | 62cm |
|---|---|---|---|---|---|---|---|---|---|
| Reach | 367.2 | 371.3 | 374.5 | 374.6 | 379.4 | 388.3 | 393.5 | 402.5 | 400.5 |
| Stack | 497.2 | 502.9 | 532.3 | 550.3 | 568.3 | 588.1 | 606.1 | 623.3 | 643.2 |
| Head Tube Angle | 70.0° | 70.0° | 71.0° | 71.0° | 71.0° | 71.0° | 71.0° | 71.5° | 71.5° |
| Head Tube Length | 110.7 | 116.7 | 144.0 | 163.0 | 182.0 | 203.0 | 222.0 | 238.0 | 259.0 |
| Seat Tube Length | 420 | 460 | 500 | 520 | 540 | 560 | 580 | 600 | 620 |
| BB Drop | 47.0 | 47.0 | 47.0 | 47.0 | 47.0 | 47.0 | 47.0 | 47.0 | 47.0 |
| Wheelbase | 1036.6 | 1042.7 | 1046.8 | 1053.1 | 1064.0 | 1079.8 | 1091.2 | 1100.4 | 1105.1 |
| Chainstay Length | 460.0 | 460.0 | 460.0 | 460.0 | 460.0 | 460.0 | 460.0 | 460.0 | 460.0 |
| Top Tube Length, Actual | 492.7 | 508.4 | 525.4 | 535.0 | 549.7 | 564.5 | 580.3 | 594.8 | 603.8 |
| Top Tube Length, Effective | 505.0 | 515.0 | 530.0 | 540.0 | 555.0 | 570.0 | 586.0 | 600.0 | 610.0 |
| Seat Tube Angle | 75.0° | 74.5° | 74.0° | 73.5° | 73.0° | 73.0° | 72.5° | 72.5° | 72.0° |
| Standover Height | 702.1 | 723.2 | 756.1 | 774.5 | 792.4 | 811.9 | 829.7 | 847.9 | 866.6 |
| Fork Length | 376.0 | 376.0 | 376.0 | 376.0 | 376.0 | 376.0 | 376.0 | 376.0 | 376.0 |
| Fork Rake | 45.0 | 45.0 | 45.0 | 45.0 | 45.0 | 45.0 | 45.0 | 45.0 | 45.0 |
700c
| SIZE | 56cm(700c) | 58cm(700c) | 60cm(700c) | 62cm(700c) | 64cm(700c) |
|---|---|---|---|---|---|
| Reach | 389.3 | 394.4 | 403.0 | 401.0 | 406.1 |
| Stack | 588.0 | 606.1 | 623.2 | 643.2 | 658.4 |
| Head Tube Angle | 72.0° | 72.0° | 72.0° | 72.0° | 72.0° |
| Head Tube Length | 152.0 | 171.0 | 189.0 | 210.0 | 226.0 |
| Seat Tube Length | 560.0 | 580.0 | 600.0 | 620.0 | 640.0 |
| BB Drop | 78.0 | 78.0 | 78.0 | 78.0 | 78.0 |
| Wheelbase | 1055.6 | 1066.7 | 1080.8 | 1085.3 | 1095.3 |
| Chainstay Length | 460.0 | 460.0 | 460.0 | 460.0 | 460.0 |
| Top Tube Length, Actual | 564.5 | 580.2 | 594.8 | 603.9 | 615.0 |
| Top Tube Length, Effective | 570.0 | 586.0 | 600.0 | 610.0 | 620.0 |
| Seat Tube Angle | 73.0° | 72.5° | 72.5° | 72.0° | 72.0° |
| Standover Height | 811.9 | 829.8 | 847.8 | 866.5 | 883.6 |
| Fork Length | 390.0 | 390.0 | 390.0 | 390.0 | 390.0 |
| Fork Rake | 45.0 | 45.0 | 45.0 | 45.0 | 45.0 |
